DZ47-63-1P
KCISE
| Current: | |
|---|---|
| Quantity: | |
| Place of Origin | WENZHOU | brand | KCISE |
|---|---|---|---|
| Pole Number | 1P | Breaking Capacity | 22-55KA（KA） |
| 极数 | 1P | Instantaneous tripping characteristic | C |
| rated current of tripper | 63A | rated voltage | 400V（V） |
| residual current tripper type | C ,D | residual current type | C，D |
| residual operating current | 30mA | residual operating time | 0.1S |
| mechanical life | 100000 times | switch width | 18mm |
| frame current | 63A（A） | rated impulse voltage | 3000V |
| operation mode | manual operation | tripping mode | overcurrent tripper |
| characteristic | ordinary type | protection type | tripper protection |
| application scenario | terminal power distribution | wiring mode | front panel wiring |
| model | DZ47-63/1P 6A,DZ47-63/1P 10A,DZ47-63/1P 16A,DZ47-63/1P 20A,DZ47-63/1P 25A,DZ47-63/1P 32A,DZ47-63/1P 40A,DZ47-63/1P 50A,DZ47-63/1P 63A | series | DZ47-63 |
| product certification | CCC | width | 18（mm） |
| purpose | residual current protection | minimum packaging quantity | 1piece |
| shell cover | white shell/transparent | 3C rated voltage range | AC rated voltage 1500V and below |
| structure type | molded case circuit breaker | arc extinguishing medium | air type |
Product Overview ：
This DZ47-63 (commonly known as C45) 1P miniature circuit breaker is designed for single-phase circuits with AC 50/60Hz and a rated voltage of 230/400V. It is primarily used for overload and short-circuit protection in residential buildings, office buildings, factories, photovoltaic systems, and other similar applications. It can also be used as a disconnecting switch for circuits with infrequent switching. With its compact structure, easy installation, and stable performance, it is the preferred protective component for modern low-voltage power distribution systems.
Key Parameter Highlights：
Number of Poles: 1P (Single-pole, protects single-phase live wire)
Rated Current (In): 6A / 10A / 16A / 20A / 25A / 32A / 40A / 50A / 63A (Multiple specifications available)
Trip Characteristics: C-shaped curve (5-10In instantaneous magnetic tripping, suitable for general loads such as lighting, sockets, motor starting, etc.)
Rated Short-Circuit Breaking Capacity (Icn): 4500A / 6000A (some models have higher capacity)
Rated Operating Voltage: AC 230V (single-phase) / 400V (can be used for single-pole protection in multi-phase systems)
Installation Method: Standard 35mm DIN rail quick-mount, 18mm width (1 module), saving distribution box space
Mechanical/Electrical Life: Mechanical ≥20,000 cycles, Electrical ≥10,000 cycles, longer service life Housing Material: High flame-retardant and impact-resistant PC material, fireproof and moisture-proof, safe and reliable.
Protection Rating: IP20 (terminal shockproof)
Certifications: Complies with GB10963.1 / IEC60898 standards, CCC and CE certified (some models support CB and RoHS).
Main Functions and Advantages:
Dual Protection: Thermal-magnetic tripping (overload delay + short-circuit instantaneous tripping) quickly and reliably interrupts fault current.
Contact Status Indication: Clearly displays ON/OFF/TRIP positions for quick troubleshooting.
Comfortable Handle Operation: Curved design, non-slip and labor-saving, supports padlock function (for easy maintenance and safety).
Easy Wiring: Terminals can connect to rigid/flexible wires, maximum wiring cross-section 25mm².
Compact Size: Only 18mm wide, perfectly fits modern small distribution boxes.
Wide Applications: Home lighting, socket circuits, air conditioners, water heaters, photovoltaic grid connection, small motor control, main/branch protection in distribution boxes, etc.
