SSR-40DA
KCISE
SSR-40DA
Availability: | |
---|---|
Quantity: | |
The Single Phase SSR Solid State Relay is a leap forward in switching technology, offering a silent, efficient, and reliable alternative to traditional mechanical relays. This advanced relay is designed to handle significant loads up to 5kW, making it a versatile solution for both residential and commercial applications. Its silent operation and robust design ensure that it can be seamlessly integrated into a variety of systems without the noise and wear associated with mechanical switches.
· Load Capacity: Rated for a maximum load of 5kW, the SSR is a powerhouse capable of managing substantial electrical loads with ease, making it suitable for a wide array of single-phase applications.
· Input Voltage: The relay accepts a standard 24V AC/DC control signal, ensuring compatibility with a broad range of control systems and making it a user-friendly choice for system integrators.
· Output Voltage: Rated for a 380V AC output, the SSR is designed to meet the demands of single-phase power applications, providing a stable and reliable power source.
· Zero Crossing Technology: Utilizing zero crossing technology, the SSR minimizes electrical noise and interference, ensuring a smooth and quiet operation that is particularly beneficial in noise-sensitive environments.
· Fast Switching Speed: The SSR's rapid on/off switching capabilities are a game-changer for applications that require instant control, such as in precision manufacturing or laboratory settings.
· Isolation: The relay's complete electrical isolation between the control and load circuits is a critical safety feature that protects both the control system and the load from potential damage, making it an essential component in safety-critical applications.
· Longevity: With no moving parts to wear out, the SSR is built to last, capable of enduring millions of switching cycles without any loss of performance.
· Easy Installation: The compact and lightweight design of the SSR means it can be installed in tight spaces with ease, reducing installation time and costs while allowing for flexible placement within existing systems.
The Single Phase SSR Solid State Relay is a versatile component that is utilized across a diverse range of applications where the seamless and reliable switching of electrical loads is essential. Applications include:
· HVAC systems, where the SSR can be used to control heating elements and motors with precision, leading to energy savings and improved system efficiency.
· Industrial machinery, where the SSR's ability to handle high-power loads is crucial for motor and process control, enhancing productivity and operational safety.
· Lighting systems, where the SSR can be employed for dimming and on/off control, offering a more energy-efficient and responsive lighting solution.
· Home appliances such as electric ovens, water heaters, and air conditioners, where the SSR provides a silent and reliable switching solution that enhances the user experience.
· Renewable energy systems, where the SSR is used for managing solar inverters and wind turbine generators, contributing to the efficiency and reliability of these systems.
· Laboratory equipment and medical devices, where the SSR's precision control is essential for maintaining the integrity of experiments and the safety of patients.
The SSR's ability to switch high-power loads silently and with high precision makes it an indispensable component in modern electrical systems, where reliability and performance are paramount. Its adoption in various industries is a testament to its versatility and the trust it inspires in engineers and technicians who rely on it to keep their systems running smoothly and efficiently.
DESCRIPTION:
input | |||||||
Control voltage range | 470KΩ-560KΩ/2w | ||||||
output | |||||||
output voltage range | 7%-95% | ||||||
Maximum load current | 10-220VAC/10-380VAC | ||||||
Peak resistance | 600VAC | ||||||
lnsulation resistance | NA | ||||||
Leakge current in 0FF state | 10A | 25A | 40A | 60A | 80A | 100A | 120A |
Saturation depressurization in On state | ≤8mA rms | ≤8mA rms | ≤8mA rms | ≤2mA rms | ≤2mA rms | ≤2mA rms | ≤2mA rms |
The on-off response is delayed | ≤5.6V | ||||||
size | 57.4L×44.8W×28H | ||||||
weight | 100g | ||||||
Voltage resistant insulation between input and output | 2000V rms | ||||||
Voltage resistant insulation between inputand output and housing | 4000V rms | ||||||
Ambient temperature | -20ºC-75ºC | ||||||
Installation mode | bolting | ||||||
certificate | CE |
